Club 3D Radeon X800 (256 MB) Specifications, Tests and Review

Memory Size
256 MB

Memory Type
GDDR3 SDRAM

Bus Width
256-bit

Core Clock
390 MHz

Max. Resolution
2048 x 1536 at 85 Hz

Required Power Supply
350 W

Other Variants::

Get the key specs, technical data, benchmarks and full review of Club 3D Radeon X800 (256 MB) all in one place. Compare your selected model with other alternatives and give your decision on the best GPU a solid base with our comprehensive overview.

Club 3D Radeon X800 (256 MB) Full Specifications and Benchmark

general performance memory (ram) system requirements video input video output

GENERAL Club 3D Radeon X800 (256 MB)

Product Type	Graphics card
Bus Type	PCI Express x16
Graphics Engine	ATI Radeon X800
Max. Resolution	2048 x 1536 at 85 Hz
Max. Monitors Supported	2
RAMDAC	400 MHz
Interfaces	1 x DVI-I - 24+5 pin combined DVI 1 x VGA - 15 pin HD D-Sub (HD-15) 1 x VIVO
API Supported	DirectX 9.0, OpenGL 2.0
Features	3Dc

PERFORMANCE Club 3D Radeon X800 (256 MB)

Core Clock (Frequency)	390 MHz

MEMORY (RAM) Club 3D Radeon X800 (256 MB)

RAM Memory Size	256 MB
RAM Technology	GDDR3 SDRAM
Bus Width	256-bit

SYSTEM REQUIREMENTS Club 3D Radeon X800 (256 MB)

OS Required	Linux, Microsoft Windows 2000 / XP, Microsoft Windows XP Media Center Edition
System Requirements Details	Linux - Pentium RAM 128 MB Windows 2000/XP - Pentium RAM 128 MB Windows XP Media Center Edition - Pentium RAM 128 MB
Required Power Supply	350 W
Additional Requirements	CD-ROM

VIDEO INPUT Club 3D Radeon X800 (256 MB)

Type	Video in

VIDEO OUTPUT Club 3D Radeon X800 (256 MB)

Supported Display Graphics	VGA (640x480), XGA (1024x768), SVGA (800x600), SXGA (1280x1024), UXGA (1600x1200), QXGA (2048x1536), 1152x864, WUXGA (1920 x 1200), 1920x1440, 1920x1080
