AMD Radeon HD 6570 (1 GB) Specifications, Tests and Review

Memory Size
1 GB

Memory Type
DDR3 SDRAM

Effective Memory Speed
900 MHz

Bus Width
64-bit

Core Clock
650 MHz

Max. Resolution
2560 x 1600 at 60 Hz

Other Variants::

Get the key specs, technical data, benchmarks and full review of AMD Radeon HD 6570 (1 GB) all in one place. Compare your selected model with other alternatives and give your decision on the best GPU a solid base with our comprehensive overview.

AMD Radeon HD 6570 (1 GB) Full Specifications and Benchmark

general performance memory (ram) system requirements video output miscellaneous

GENERAL AMD Radeon HD 6570 (1 GB)

Product Type	Graphics card
Bus Type	PCI Express 2.0 x16
Graphics Engine	AMD Radeon HD 6570
Max. Resolution	2560 x 1600 at 60 Hz
Max. Resolution Details	DVI: 2560 x 1600 / DisplayPort: 2560 x 1600 / VGA: 2048 x 1536
Max. Monitors Supported	3
RAMDAC	400 MHz
Interfaces	DVI-I (dual link) 2 x DisplayPort VGA - with adapter DVI-D (dual link) - with adapter
API Supported	DirectX 11, OpenGL 4.0
Features	Avivo Technology, AMD Eyefinity Technology, HDCP

PERFORMANCE AMD Radeon HD 6570 (1 GB)

Core Clock (Frequency)	650 MHz

MEMORY (RAM) AMD Radeon HD 6570 (1 GB)

RAM Memory Size	1 GB
RAM Technology	DDR3 SDRAM
Effective Clock Speed (Frequency)	900 MHz
Bus Width	64-bit
Bandwidth	28.8 GBps

SYSTEM REQUIREMENTS AMD Radeon HD 6570 (1 GB)

OS Required	Microsoft Windows XP Home Edition, Microsoft Windows XP Professional, Microsoft Windows 7 Home Premium, Microsoft Windows 7 Home Basic, Microsoft Windows Vista Business (32/64 bits), Microsoft Windows Vista Home Basic (32/64 bits), Microsoft Windows Vista Ultimate (32/64 bits), Microsoft Windows 7 Professional (32/64 bits), Microsoft Windows 7 Ultimate (32/64 bits)

VIDEO OUTPUT AMD Radeon HD 6570 (1 GB)

Supported Display Graphics	VGA (640x480), XGA (1024x768), SVGA (800x600), SXGA (1280x1024), UXGA (1600x1200), HDTV (1920x1080), QXGA (2048x1536), WUXGA (1920 x 1200), 1920x1440, HD (1280 x 720), 1440x900, WSXGA+ (1680 x 1050), 2560x1600

MISCELLANEOUS AMD Radeon HD 6570 (1 GB)

Cables Included	1 x DisplayPort-DVI adapter 1 x DVI-VGA adapter
Software Included	Drivers & Utilities
Compliant Standards	FCC Class B certified, VCCI, C-Tick, BSMI, CISPR 24, ICES-003, EN55024, CISPR 22, FCC Part 15 B, EMC, KCC
